INTECH Optical Touch Panel

  • Optical 10 points touch
  • UHD 4K screen
  • Dual OS: Windows + Android OS
  • Screen sharing with mobile devices
  • Front fingerprint locker
  • Hidden front ports
  • Smart pen to remote control of the PPT
  • Special 2048 level original stylus
Features Specifications Dimensions Video
  • Optical 10 points touch
  • UHD 4K screen
  • Dual OS: Windows + Android OS
  • Screen sharing with mobile devices
  • Front fingerprint locker
  • Hidden front ports
  • Smart pen to remote control of the PPT
  • Special 2048 level original stylus
  • Front built-in camera as optional
  • Built-in sound pickup as optional

  • Model

    TS65DW Optical

    TS75DW Optical

    TS85DW Optical

    TS100DW Optical

  • Display

  • Panel Size

    65"75"85"100"

  • Overall Size (mm)

    1485.6*903*92.51725*1042.6*109.61961*1183.5*125.72297*1373.5*115.3

  • Packing Size (mm)

    1600*1025*2151870*1150*2202110*1315*2402500*1630*440

  • Display Area (mm)

    1428.5(H)*803.5(V)1650(H)*928(V)1876(H)*1057(V)2203(H)*1239(V)

  • Brightness

    ≥450cd/㎡

  • Dot Pitch

    0.4298 mm x 0.4298 mm

  • Color

    8 bit/1.07 Billion

  • Backlight

    DLED

  • Chips

    MSD6A828

  • Storage

    2G+RAM 4G

  • Technology

    Optical 10 points touch

  • Response Time

    ≤5ms

  • Calibration Accuracy

    3mm

  • Touch Surface

    4mm fully tempered anti-glare explosion – proof glass

  • Lifespan

    ≥50000h

  • Power

    ≦250W≦250W≦350W≦450W

  • Voltage

    100V-240VAC, 50/60Hz

  • Speaker

    8Ω/15W*2

  • OPS Port

    42mm standard 80Pin port

  • Wall Mount Bracket

    B75 bracket≦B85 bracketB85 bracketXD2176 bracket

  • Built-in Camera

    Standard5 million pixels camera, UVC for Windows 7 above, facial recognition (Optional)

  • Built-in Sound Pickup

    StandardEffective Distance: 5-8m (Optional)

  • 5G Screen Share Module

    Screen share software, screen share device (Optional)

  • Ports

  • Input

    VAG*1, AV*2, HDMI*1, MIC*1, YPbPr*1

  • Output

    VAG*1, AV*1, Earphone*1, SPDIF*1, USB*4, RF45*2Android 6.0

  • Android

  • Android Version

    5.1

  • Chips

    MSD6A828EVC

  • CPU

    Cortex A53*2 1.4GHz

  • GPU

    Mail450MP4(4+2) 600MHZ

  • RAM

    2G DDR3

  • Flash

    2G DDR3

  • SD Card

    Support MAX 128GB SD card

  • TV

  • ATV

    NTSC, PAL, SECAM

  • DTV

    DTMB

  • PC

  • Audio/Video IN

    Support 3840*2160P

  • Multimedia

  • Video

    MPEG-2/4, AVS, H.264, H.265, TS, Realmedia...

  • Audio

    MPEG1/2 layer Ⅰ/Ⅱ, AC-3(Customize)...

  • OPS PC (Optional)

  • CPU

    Intel Core I3/I5/I7 for options

  • Storage

    4G

  • SSD

    128G
