Interactive Draw Wall INTECH DR-86BB

  • LG In-Cell PCAP touch LED panel,
  • 4K UHD display
  • powerful Android 11.0 OS
  • NFC power on/off
  • USB port for easy collaboration
  • quick access with front physical buttons
Features Specifications Dimensions Video
  • Original LG In-Cell PCAP touch LED panel, compatible with Wacom active pen
  • Optical bonding PCAP technology
  • Front 3xUSB3.0, full function USB-C, Light sensor and system reset pinhole button
  • Android 11.0 4G RAM, 32G EMMC (8G+64G/128G as option)
  • NFC to power on/off
  • Front button: 3 in 1 Power button, Menu, Lock, Eye-Protection, Screen record, Volume+/-, screen cut

  • Product Overview

  • Model

    DR-86BB

  • Color

    black

  • Material

    aluminum + metal

  • Touch Technology

    LG In-Cell PCAP touch

  • Built-in Camera

    12MP 4K camera (optional)

  • Built-in Microphone

    8 array mic (optional)

  • Display

  • Size

    86 inch

  • Backlight Type

    D-LED

  • Display Area

    1895(H)mm * 1065.96(V)mm

  • Resolution

    3840*2160

  • Brightness

    350cd/m²

  • Contrast Ratio

    1000:1

  • Response Time

    8ms

  • Refresh Rate

    60Hz

  • View Angle

    ≥ 178°

  • Touch

  • Glass

    3mm anti-glare tempered glass

  • Touch Technology

    In-cell PCAP touch

  • Touch Points

    20 points

  • Response Time

    5ms

  • Connection

    USB driver free

  • Touch Method

    finger or PCAP pen

  • Light Resistance

    80K Lux

  • Compatible System

    Android/Win7/Win8/Win10

  • OS

  • Android Version

    Android 11.0

  • CPU/GPU

    CA55*4

  • RAM

    4GB

  • ROM

    32 GB

  • Video Format

    MKV, WMV, MP4, MPG, AVI, MPEG, ISO, etc.

  • Front Ports

    HDMI*1, Touch*1, USB-C*1, USB3.0*3

  • Rear Ports

    LAN IN*1, LAN OUT*1, AV IN*1, AV OUT*1, Earphone OUT*1, SPDIF*1, HDMI IN*2, Touch*1, RS-232*1, USB2.0*1, USB3.0*1, TF-CARD*1, HDMI OUT*1, MIC*1, DP IN*1, VGA*1, YPBPR*1, Audio*1

  • Speakers

    15W * 2 (Face Front)

  • Power

  • Input Voltage

    110-220V~50/60Hz

  • Power Consumption

    450W

  • Standby Power Consumption

    ≦0.5W

  • Rocker Switch

    Yes

  • Connection

    AC

  • Environment

  • Working TEMP

    0～50℃

  • Storage TEMP

    -20～+60℃

  • Working Humidity

    20% ~ 80%

  • Storage Humidity

    10%RH ～ 90%RH

  • Life

    ≥50000Hours

  • Physical Spec

  • Product Dimension

    4200(L)*1200(H)*96.05(W)mm

  • Product Dimension (include wall-mount bracket)

    4200(L)*1200(H)*101(W)mm

  • Package Material

    Carton

  • Package Dimension

    2161(L)*1314(H)*288(W)mm

  • N/W

    40KG

  • G/W

    110KG

  • Accessories

  • Quick Start Manual

    1 PC

  • Remote Control

    1 pc

  • PCAP Pen

    1 PC

  • Wall Mount Bracket

    1 set

  • Power Cord

    1 PC (3m)
